Reliable Performance From the Ground Up

JTS Vertical Turbine Pump

The JTS Vertical Turbine Pump delivers dependable water movement for demanding municipal applications. Engineered for efficiency and long-term reliability, the JTS handles clear, raw, or reclaimed water with ease. Its rugged design ensures smooth operation in deep well and sump settings, minimizing maintenance and maximizing uptime.

Speak to an Industry Expert

Available on all Johnston Pump product lines

Available for JTS product Line

Designed & Engineered to Meet Project Requirements

The JTS Vertical Turbine Pump is highly engineered to meet demanding applications. It features fully updated hydraulics and mechanical designs to improve efficiency and ROI and reduce maintenance needs. Like all of Johnston’s turbine pumps, the JTS is available with NSF certification for potable water service. The JTS pump is best suited for the following applications:

Agricultural Pumping

Municipal & Plant Water Supply

Drainage

Potable Water Supply

Raw Water Intake

Effluent Transport

Filter Backwash

Highly Engineered Features

Standard Features

The JTS Vertical Turbine Pump is modular, designed to withstand harsh, corrosive environments, and is highly adaptable based on application needs. Explore the standard features of our JTS model:

Ensure Reliably Clean Water

Why Choose Johnston JTS

Our highly modular JTS Vertical Turbine Pump can handle flows up to 25,000 gpm and up to 1,000 feed of head and temperatures up to 185°F. The JTS pump features a closed design for higher efficiency and consistent performance in clean water applications. Some of the other benefits of JTS include:

NSF-Certified: Safe for potable water applications.

Space-Saving Design: Requires minimal floor space.

No Priming Needed: The pump bowl assembly is submerged for instant operation.

Highly Adaptable: Customizable pump length and location flexibility.

Efficient Performance: Low operating speeds and staged pressure options.

Corrosion-Resistant Options: Multiple coatings available for harsh environments.

Low Maintenance: Trouble-free operation with easy service.

Flexible Configurations: Easily modified for changing hydraulic conditions.

View Technical Specifications

Technical Data

View the table below for specific information regarding our JTS pump.

Pump Part	Material
Bowls	Cast iron, ASTM A48 CL. 30
Impellers	Chrome steel, ASTM A743 CA-6NM; stainless steel A734 CF-8M
Impeller wear rings	Aluminum bronze, ASTM B148 alloy C95400
Stationary wear rings	Nickel aluminum bronze, ASTM B148 alloy C95500
Suction bell	Cast iron, ASTM A48 CL. 30
Bearing bushing	Bronze, ASTM B584 alloy C87300; rubber, C425-65 (oil resistant)
Discharge head	Cast iron, ASTM A48 CL.40, carbon steel, ASTM A36 and A53 Gr. B
Shafts	Stainless steel, ASTM A582 Type 416 Cond. A
Sole plates	Cast iron, ASTM A48 CL.40F

	60 Hz
Bowl sizes	6 to 36 in.
Capacities	Up to 25,000 USgpm
Heads	Up to 1,000 ft.
Temperatures	35°F to 185°F

JTS Vertical Turbine Pump performance range graph

Get the Flexibility You Need

Optional Configurations

All pumps, including the JTS, can be configured with these optional features to improve performance:

Flanged Column Assembly

Standard for sizes 14”/355mm and 16”/410mm, available as an option for all other sizes.

Fabricated Discharge Head

Fabricated discharge heads are available for all sizes with flange ratings of 150# or 300#.

Sole Plate

Sole Plates are available in custom sizes to meet project requirements.

Strainers

Basket, Cone, and Flow Conditioning Basket Strainers available in stainless steel.

Enclosed Lineshaft

Optional enclosed lineshaft is designed for deep well service where abrasives and contaminates are present.

Do You Need the JTS?

Learn More About the JTS Pump

Get more information about the JTS pump, including performance specifications, installation guidance, and more.

Brochure

Are you interested in learning more about our JTS pump? Download our brochure for additional data.

Download

Manual

Have you purchased the JTS pump? Download our manual for comprehensive installations instructions, maintenance requirements, and troubleshooting.

Download
